Fuji Medical Dry Imager

Fuji Medical Dry Imager
Fuji Medical Dry Imager
Send Inquiry
Product Code : Drypix 2000
Product Description

Fuji Medical Imager DRYPIX Lite Specifications

Basic Specifications

Standard Component

Fuji Medical Dry Imager DRYPIX Lite (Model: DRYPIX 2000)

Recording method

Thermal head transfers heat while in contact with thermal film

Applicable film

Fuji Medical Dry Film DI-HT 35 x 43 (14 x 17), 26 x 36, 25 x 30 (10 x12), 20 x 25 (8 x10)

Film loading

Daylight film loading

Film magazines

I Up to 2 magazines

Processing capacity

Approx. 50 sheets/hour 35 x 43 (14 x17), Approx. 75 sheets/hour 26 x 36,

Approx. 65 sheets/hour 25 x 30 (10 x12), Approx. 90 sheets/hour 20 x 25 (8 x10)

Approx. 65 sheets/hour 25 x 30 (10 x12), Approx. 90 sheets/hour 20 x 25 (8 x10)

Pixel size

I 84.7µm (30odpi)

Recording gradation

12 bits

Image memory

1 GB

Density adjustment

Automatic

Input channels

DICOM network input x1 channel only

Physical Characteristics

External dimensions (W x D x H)

530 x 590 x 365mm (21 x 23 x 14") with Large magazine/530 x 470 x 365mm (21 x19 x14") with Small magazine

180mm higher with optional sheet-feeder unit

Weight

32 kg (71 lbs.) /43 kg (95 lbs.) with Optional sheet-feeder unit

Power supply

Input voltage: AC100-24oV / Phase: Single / Frequency: 50-6oHz / Rated current: 5-2A

Operating Environment

Temperature

15-30ºC

Humidity

40-70% RH (at 15°C) to 15-70% RH (at 30°C) (no dew condensation)

Options

  • Optional sheet-feeder unit (*Supply magazine not included [Purchase separately]
  • Vehicle mounting kit * Cart (*Cart does not conform to UL requirements.)
  • Large magazine * Small magazine
  • DRYPIX Lite doesn't come standard with supply magazine. Purchase magazine accordingly.
  • Large magazine can only accommodate 35 x43 (14 x 17) film size.
  • Small magazine can accommodate either 26 x 36, 25 x 30 (10 x 12) or 20 x25 (8 x 10) film size.
  • To set up the film size to your desired size requires the support of our servicing personnel.
  • Once the magazine is set to a film size, you cannot change it to a different one by yourseif.
  • Film sizes indicated above required the respective magazines, as desired.
